Infomir IPTV MAG522 / MAG522W3 Linux 4K 1G/4G

118134.99 Inc.VAT

  • 4 GB eMMC
  • 1 GB DDR3
  • Quad-Core ARM Cortex-A53
  • Amlogic S905X2
  • 4K
  • Linux 4.9
Infomir-MAG522
Infomir IPTV MAG522 / MAG522W3 Linux 4K 1G/4G 118134.99 Inc.VAT
SKU: N/A Categories: Tags: ,

🚚 We deliver all over Cyprus

Guaranteed Safe Checkout

payment-options

Infomir IPTV MAG522 / MAG522w3

The Infomir IPTV MAG522 and MAG522w3 are high-performance Linux set-top boxes. These devices are powered by an Amlogic S905X2 chipset with a 25% more powerful ARM Cortex-A53 CPU, enabling them to playback 4K content smoothly at 60 fps.

The devices enable operators to offer their users the best user experience and seamless service. Their APIs correspond to those of previous models to ensure that the set-top boxes can be easily integrated by operators who have previously used MAG devices. Additionally, upon request, we can integrate MAG522 and MAG522w3 with third-party middleware and content protection systems.

MAG522 / W3 Features

Linux 4.9: get the best user experience
The media player Infomir MAG522 can operate without rebooting for several months. Linux OS enables operators to customize the UI and develop bespoke applications.

Powerful Amlogic Chipset
The set-top box MAG522 is 25% more powerful than their predecessors thanks to an Amlogic S905X2 chipset and ARM Cortex-A53 CPU.

Ethernet Port & Wi-Fi

The MAG522model uses a 100 Mbps Ethernet interface and operates over a wired network.
The MAG522W3 model uses a 100 Mbps Ethernet port and dual-band Wi-Fi module. The 2.4 GHz band provides a speed of up to 100 Mbps, while the 5 GHz band offers up to 550 Mbps.

Built-in HEVC And 4K Technologies
The set-top box easily and smoothly play content in the most popular modern formats including 4K at 60 fps. 1 HEVC codec support means the device can play high-definition content at slow Internet speeds.

API For Integrations
Infomir’s API has been specifically created for easy integration of content protection systems and software development. Operators develop applications using Infomir’s documentation. These can be web pages using HTML, CSS, and JavaScript.

Three-Dimensional Dolby Digital Plus™ Sound
Through 8-channel sound technology, users are able to connect media players to modern audio systems, home theatres, and TVs.2

1. A compatible TV is required for 4K content playback.
2. A TV or home theatre supporting Dolby Digital Plus™ is require

Additional information

Brand

Model

MAG 522 100Mbps Ethernet, MAG 522w3 Wi-Fi Dual Band

Operating System

Interfaces

, , ,

Connectivity

,

Chipset

Amlogic S905X2

Processor

Quad-core ARM Cortex-A53, 1,900 MHz

GPU

ARM Mali Dvalin MP2, 850 MHz.
Supports OpenGL ES 3.2, Vulkan 1.0
and OpenCL 2.0

Performance

18,400 DMIPS

RAM

Internal Storage

Sources Of Media Content

PC or NAS, multimedia broadcasts, USB devices

Audio Codecs

MPEG L1/L2/L3l, AAC-LC, HE AAC V1/V2, APE, FLAC, Dolby Digital Plus™

Video Codecs

MPEG1/2 MP@HL, MPEG4 part 2 (ASP), H.265 Main/Main 10@L5.1 High 2160p@60 fps (optionally), H.264 AVC High@L5.1 2160p@30 fps, XviD, 3D video support

Video Formats

TS, MTS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB, 3GP

Image Formats

JPEG, PNG, BMP, RAW

Playlist Formats

M3U, M3U8, PLS, CUE

Resolution

, , , ,

Video Modes

PAL, NTSC

Subtitles

DVB, PGS, SRT, SSA/ASS, SUB, Teletext, WebVTT, closed captions

Dimensions

132x87x26mm

Weight

125g

Power

DC 5V, 2A (DC 12V, 1А optional)

Standard Set

MAG522 set-top box, user manual, HDMI cable, 12 V 1 A power adapter (optionally, a 5 V 2 A power adapter), remote control, 2 AAA batteries, packaging
